TAMIYA VW Karmann Ghia High Performance M-06 Chassis, 1:10 Scale RWD RC Car Read more.
Electric R/C Car Series No.677
1/10 Volkswagen Karmann Ghia (M-06)
Item No: 58677
Length: 410mm. Image shows painted and assembled kit.
| A Classy Ride 1955 was the debut of the Volkswagen Karmann Ghia, which combined a Volkswagen chassis with a 2+2coupe body designed by Italian outfit Ghia and manufactured in Germany by Karmann. An air cooled flat-four engine in the back powered the rear wheels, and its fusion of looks, low ride height and affordable price tag made it a popular model that still retains a fan base in the modern day. This radio control model assembly kit depicts the car in 1/10 scale. The elegant lines of the low-slung car are accurately recreated by a polycarbonate body, with separately molded metal-plated light case, bumper and side mirror parts adding extra realism. |

 |
 |
 |
|
‚òÖLeft: The front of the model is resplendent with plated bumper and overriders. Light cases are compatible with separately sold LEDs. ‚òÖRight: The side mirror is fastened from the inside of the polycarbonate body using snap pin. This is a dedicated part for this car. |

 |
|
 |
|
‚òÖLeft: The rear bumper is also metal-plated, and rear light cases can be fitted with separately sold LEDs for an extra level of realism. ‚òÖRight: Classic metal-plated dish wheels add a further accent to the model, and are paired with grippy, treaded tires for a great drive. |

| Great RR Performance from the M-06 The M-06 chassis features a rear-mounted motor, rear-drive setup and has a longitudinally-mounted battery pack, with R/C equipment positioned on either side for optimum balance and a low center of gravity. 4-wheel double wishbone suspension uses metal-plated wheels, equipped with 60D radial tires at the front and 60D super grip tires at the rear. In addition, a 3-piece steering linkage offers nimble handling response. |

 |
|
 |
|
‚òÖLeft: The M-06 chassis' three-piece steering linkage ensures you have great control and direct steering feel. ‚òÖRight: A close-up on the independent double wishbone front suspension setup, which employs friction dampers. |

 |
|
 |
|
‚òÖLeft: The rear-mounted motor, rear-wheel drive setup provides the model with excellent traction at the rear. ‚òÖRight: A close-up on the rear suspension. Use separately sold pinion gears to achieve different gear ratios. |

| Specifications ‚òÖLength: 410mm, Width: 182mm, Height: 125mm ‚òÖWheelbase: 239mm ‚òÖTread (F/R): 138mm ‚òÖRear-Motor, Rear-Wheel Drive ‚òÖ3-Bevel Differential Gear ‚òÖ3-Piece Steering Tie-Rod ‚òÖ4-Wheel Independent Double Wishbone Suspension ‚òÖF/R Friction Dampers ‚òÖGear Ratio = 5.8:1 (using kit-standard 20T pinion) ‚òÖTire Width/Diameter (F/R): 25mm/59mm ‚òÖType 540 Motor ‚òÖRequires an Electronic Speed Controller (sold separately) |

| Separately Required Items ‚òÖ2-Channel R/C System w/ESC ‚òÖR6/AA/UM3 batteries for transmitter ‚òÖBattery pack & charger |
