The Power HD TDS-2 is a high-performance, low-profile servo designed for demanding applications.
With its coreless motor, titanium and steel gears, and dual ball bearings, this servo delivers exceptional speed and torque. It's ideal for 1/10 scale crawlers, buggies, and trucks where precision and responsiveness are crucial.
Features
- High torque: 25kg-cm (347 oz-in) at 8.4V
- Fast speed: 0.09 sec at 8.4V
- Coreless motor for smooth and efficient operation
- Durable titanium and steel gears
- Dual ball bearings for precise movement
- Low-profile design for easy installation in tight spaces
- Compatible with program box for custom settings
- Genuine Power HD Product
Specifications
- Torque(6.0V): 18.0 kg-cm (250.0 oz-in)
- Torque(7.4V): 22.0 kg-cm (305.5 oz-in)
- Torque(8.4V): 25.0 kg-cm (347.2 oz-in)
- Speed: 0.13 sec (6.0V) | 0.10 sec (7.4V) | 0.09 sec (8.4V)
- Weight: 61 g (2.15 oz)
- Operating Voltage: 6.0V - 8.4V
- Bearing Type: Ball Bearing x 2
- Motor Type: Coreless
- Operating Temperature: -20℃~60℃
- Refresh Rate: 333Hz
Included Items
- 1x Power HD Aluminium TDS-2 8.4V 25kg Coreless Metal Geared Servo
